2.2kw 250mm Horizontal Metal Cutting Band Saw Hydraulic Feed

Brand Name : HJ

Model Number : G5225/GZ4225

Certification : ISO9001

Place of Origin : China

MOQ : 1 Set

Price : Negotiable

Payment Terms : L/C, T/T

Packaging Details : Plywood case or pallet

Style : Horizontal

Use : Metal Cutting,Woodworking

Applicable industries : Machinery Repair Shops,Manufacturing Plant,Building Material Shops

Type : Band Saw,Horizontal

Color : Customizable

Name : Band Saw Machine

Contact Now

Maximum 250 mm Horizontal Band Saw

Product information

This product is mainly used for ferrous metal material single piece or batch blanking operation. It is suitable for cutting and step processing of all kinds of metal bars with specifications of 250mm. It can be equipped with beam forming device to cut small specification materials .Widely used in variety fields of mechanical processing.

Parameters	unit	Specifications
Parameters	unit	G4225	GZ4225
Maximum saw specification
Round stock	mm	φ250	φ250
Square stock	mm	250X250	250X250
Minimum saw specification	mm
Saw blade specifications	mm	27 x0. 9 x3505	27 x0. 9 x3505
Saw blade speed	m/min	27, 40, 54, 75	27, 40, 54, 75
Feed speed	mm/s	0.2-5 (Hydraulic CVT)	0.2-5 (Hydraulic CVT)
Feeding speed	mm/s		50
Main motor power	kW	2.2	2.2
Hydraulic system pressure	MPa	2.2 ~ 2.8	2.2 ~ 2.8
Table height	mm	700	700
Maximum single feed length	mm	manual	400
Specification for clamping of bunching device	mm	250x (20-80)	250x (20-80)
Machine tool dimensions	mm	2020X1990X1350	2020X1990X1350
Net weight	kg	1400	1800
